Components used in Examples
Adafruit 1063 / 1064
Analog microphone
Adafruit 2791
Adapter Connector Stereo, 3.5mm TRS/TRRS breakout.
Adafruit 2.8” TFT LCD Touch Shield
ILI9341 TFT LCD display, touch screen with built in microSD card connection. Support SPI.
Adafruit LSM9DS1
Accelerometer with 3 acceleration channels, 3 angular rate channels, and 3 magnetic field channels. Supports I2C and SPI.
Adafruit PDM MEMS Microphone Breakout
PDM MEMS Microphone
Adafruit TXB0108
8-channel Bi-directional logic level converter.
Adafruit Ultimate GPS Breakout
High-quality GPS positioning module with -165 dBm sensitivity, 10 Hz updates, 66 channels.
Arducam Mini 2MP Plus - OV2640 SPI Camera Module
A high definition 2MP SPI camer. Supports I2C and SPI.
AS606 Fingerprint Module
Fingerprint Scanner working by 5V power.
DHT11 / DHT21(AM2301) / DHT22(AM2302)
Low cost temperature & humidity sensors working by 3 to 5V power and I/O.
DS1307
Low-power serial real-time clock. Supports I2C.
DS3231
Low-power serial real-time clock. Supports I2C.
Grove - Infrared Emitter
The Infrared Emitter is used to transmit infrared signals through an infrared LED.
Grove - Infrared Receiver
The Infrared Receiver is used to receive infrared signals and also used for remote control detection.
I2C 2×16 LCD
2×16 LCD display screen with I2C interface.
Logitech C170 Webcam
Usb 2.0 Webcam.
MPU6050
6-Axis (Gyro + Accelerometer) MotionTracking Devices. Support I2C.
PlanTower PMS3003 / PMS5003
Air quality sensor that detects concentration of micro particulate matters.
QVGA 2.2" TFT LCD
ILI9341 TFT LCD display, with built in microSD card connection. Support SPI.
RFID-RC522
RFID reader/writer IC for contactless communication.
Sparkfun 11570
TRS/TRRS 3.5mm Jack Breakout.
SparkFun SX1509 I/O Expander
16-channel GPIO expander with an I2C interface.
Tower Pro SG90
Tiny and lightweight servo with high output power.
Ultrasonic Distance Sensor - HC-SR04
Ultrasonic distance sensor module.
USB to TTL Adapter
The USB TTL Serial cables are a range of USB to serial converter cables which provide connectivity between USB and serial UART interfaces.
Waveshare E-Ink display module (296x128, 2.9inch)
E-Ink display module, 2.9inch, 296x128 resolution, with embedded controller, communicating via SPI interface, supports partial refresh.
WS2812 LED (4*4)
Intelligent control LED integrated light source.
